PRODUCTS
Optical Communication
Terminal Devices
| Picture | Product Name | Part Number | Package | Interface | Reach | Temp | Tx Output | Tx Rate | Tx Wavelength | Rx Input | Rx Rate | Rx Wavelength |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
25G BIDI | LTF2325-BH+ | SFP28 | LC | 10km | H | -4~2.2dBm | 25.78Gb/s | 1270nm | -12dBm | 25.78Gb/s | 1330nm |
 |
25G BIDI | LTF3225-BH+ | SFP28 | LC | 10km | H | -4~2.2dBm | 25.78Gb/s | 1330nm | -12dBm | 25.78Gb/s | 1270nm |
 |
25G BIDI | LTF2328-BH+ | SFP28 | LC | 40km | H | 0~6dBm | 25.78Gb/s | 1270nm | -18.5dBm | 25.78Gb/s | 1310nm |
 |
25G BIDI | LTF3228-BH+ | SFP28 | LC | 40km | H | 0~6dBm | 25.78Gb/s | 1310nm | -18.5dBm | 25.78Gb/s | 1270nm |
 |
1.25G BIDI | LTE3424-BC+ | SFP | LC/UPC | 40km | C | -2~3dBm | 1.25Gb/s | 1310nm | -23dBm | 1.25Gb/s | 1490nm |
|
1.25G BIDI | LTE4324-BC+ | SFP | LC/UPC | 40km | C | -2~3dBm | 1.25Gb/s | 1490nm | -23dBm | 1.25Gb/s | 1310nm |
|
1.25G BIDI | LTE3405-BC+ | SFP | LC/UPC | 10km | C | -9~-3dBm | 1.25Gb/s | 1310nm | -19.5dBm | 1.25Gb/s | 1490nm |
|
1.25G BIDI | LTE4305-BC+ | SFP | LC/UPC | 10km | C | -9~-3dBm | 1.25Gb/s | 1490nm | -19.5dBm | 1.25Gb/s | 1310nm |
 |
10G BIDI | LTF3205-BC+ LTF3205-BH+ |
SFP+ | LC/UPC | 10km | C.H | -8.2~0.5dBm | 10.3125Gb/s | 1330nm | -14.4dBm | 10.3125Gb/s | 1270nm |
 |
10G BIDI | LTF2305-BC+ LTF2305-BH+ |
SFP+ | LC/UPC | 10km | C.H | -8.2~0.5dBm | 10.3125Gb/s | 1270nm | -14.4dBm | 10.3125Gb/s | 1330nm |
 |
10G BIDI | LTF3204-BC+ LTF3204-BH+ |
SFP+ | LC/UPC | 40km | C.H | 0~5dBm | 10.3125Gb/s | 1330nm | -18dBm | 10.3125Gb/s | 1270nm |
 |
10G BIDI | LTF2304-BC+ LTF2304-BH+ |
SFP+ | LC/UPC | 40km | C.H | 0~5dBm | 10.3125Gb/s | 1270nm | -18dBm | 10.3125Gb/s | 1330nm |
 |
10G BIDI | LTF3202-BC+ LTF3202-BH+ |
SFP+ | LC/UPC | 20km | C.H | -4.2~4dBm | 10.3125Gb/s | 1330nm | -14.4dBm | 10.3125Gb/s | 1270nm |
 |
10G BIDI | LTF2302-BC+ LTF2302-BH+ |
SFP+ | LC/UPC | 20km | C.H | 10.3125Gb/s | 1270nm | 10.3125Gb/s | 1330nm | ||
 |
1.25G CSFP | LTM4302-BC+ LTM4302-BH+ |
CSFP | LC | 20km | C,H | -9~-3dBm | 1.25Gb/s | -23dBm | 1.25Gb/s | ||
 |
1.25G CSFP | LTM4301-BC+ LTM4301-BH+ |
CSFP | LC/UPC | 10km | C,H | -9~-3dBm | 1.25Gb/s | 1490nm | -19.5dBm | 1.25Gb/s | 1310nm |
 |
1.25G CSFP | LTM4302-BC+ LTM4302-BH+ |
CSFP | LC/UPC | 20km | C,H | -9~-3dBm | 1.25Gb/s | 1490nm | -23dBm | 1.25Gb/s | 1310nm |
