GPON STICK
LTE3415
The LTE3415 SFP GPON ONU stick module has been designed for FTTx applications. LTE3415 is an GPON ONU device designed with the ITU-T G984 standard . It is a cost-effective GPON customer premise system and can provide 1244Mbps upstream / 2488Mbps downstream Broadband services by connecting subscriber’s switches or routers
ADD TO CARTStandards: ITU-T G.984.x
Package： SFP+
Optical Module: Class B+
Data rate: 2.488Gbps/1.244Gbps D/U
Wavelength: 1310nm/1490nm
Optical interface: SC/APC, SC/UPC
Max Distance: 20KM
TX Output: +0dBm-+5.0dBm
RX Input: < -28dBm
Operating Temperature Range:
Industrial : -40 to 85 ºC
Commercial : 0 to 70 ℃
Power Consumption ＜ 2w
Supporting 1000BASE-X/2500BASE-X/SGMII/HSGMII interface
