10G EPON STICK
LTF7263
The LTF7263 10G EPON ONU STICK module has been designed for low cost Point-to-Multi Point (P2MP) Fiber to the Home (FTTH), Building or Curb (FTTx) applications employing high-speed Burst Mode TDM Upstream at 10.3125Gb/s and CW Downstream at 10.3125Gb/s.
ADD TO CARTStandards: IEEE 802.3av
Package： SFP+
Optical Module: PR30
Data rate: 10.3125Gb/s /10.3125Gb/s D/U
Wavelength: 1270nm/1577nm
Optical interface: SC/UPC
Max Distance: 20KM
TX Output: +4dBm ~ +9dBm
DpoE
RX Input: < -28dBm
Operating Temperature Range:
Industrial : -40 to 85 ºC
Commercial : 0 to 70 ℃
Power Consumption ＜ 3w
