XGSPON STICK
LTF7267
The LTF7267 XGSPON ONU STICK module has been designed for low cost Point-to-Multi Point (P2MP) Fiber to the Home (FTTH), Building or Curb (FTTx) applications employing high-speed Burst Mode TDM Upstream at 9.95328Gb/s and CW Downstream at 9.95328Gb/s.
ADD TO CARTStandards: ITU-T G.984.3 /G.988/ G.9807.1/ G.987.3
Package： SFP+
Optical Module: N1.N2,E1
Data rate:9.95328Gb/s /9.95328Gb/s D/U
Wavelength: 1270nm/1577nm
Optical interface: SC/APC, SC/UPC
Max Distance: 20KM
TX Output: +4dBm ~ +9dBm
1pps+ToD
RX Input: < -28dBm
Operating Temperature Range:
Industrial : -40 to 85 ºC
Commercial : 0 to 70 ℃
Power Consumption ＜ 3w
